Snapshots
| Toolbar | Menu |
|---|---|
|
|
Window Panels > Snapshots |
Snapshots 指令可以保存以及恢复下列内容的快照:
图层
灯光
网格编辑
物件
渲染
视图
快照面板
快照恢复
-
Double-click a snapshot thumbnail.
另存
对新快照进行保存和命名。
创建快照
- 选取一个工作视窗。
-
确保没有选中任何快照。
-
Click the Save as
button. -
输入快照的名称。
-
选取快照要保存的参数。
更新快照
-
选择一个快照名称。
-
Click the Save
button. - 选择新的快照以替换当前快照。
删除
删除选取的快照。
还原
还原选取的快照。
- Double-click a snapshot thumbnail to restore.
- 当您将一个快照还原到一个未保存的视图时，会提醒您将未保存的视图保存为一个快照。
显示详情...
查看如果您选择了“否”会丢失哪些信息。
是
在还原快照之前保存当前建模状态的快照。
否
忽略当前未保存的信息并还原快照。
取消
停止还原快照。
Do not show this message again
Saves the current settings and turns off the dialog display.
To turn the message back on
See also: ResetMessageBoxes command.
部分还原
还原所选快照的部分列表。
编辑
重新检查或删除存储在所选快照中的项目。
在删除快照数据对话框中...
-
点击
删除数据。 -
Before clicking , click
Reset to restore all data deletions.
从 3dm 文件导入
从一个 Rhino 文件导入快照。
Animation
Animates the restoration of the snapshot. When you change to a different snapshot, the snapshot transitions smoothly from the current conditions to the selected snapshot. This allows you to see the transition and can also be used to build presentations.
- Double-click the snapshot thumbnail to start the animation.
Note for view animation
Snapshots do not animate between parallel (ortho) and perspective views because perspective views have a lens length that does not exist in parallel views. You will only see smooth view transition between parallel views or between perspective views, but not a mix.
Animation Settings
Animate snapshot restoration
Play animation when restoring a snapshot.
Constant time ____ frames
When:
Constant time = 100 frames
Delay between frames = 10 milliseconds
The animation takes 10 x 100 = 1000 milliseconds (1 second).
Constant speed ____ units per frame
When:
Constant speed = 0.1 units per frame
Delay between frames = 10 milliseconds
If a view moves 20 units between snapshots, the animation takes 10 x 20 / 0.1 = 2000 milliseconds (2 seconds).
Delay between frames ____ milliseconds
The delay time between frames.
Start SlideshowSlideshow Settings
Fullscreen
Floating view
Maximize active view
Repeat
Loop the animation.
Show each snapshot for <x> seconds
Set interval for displaying each snapshot.
右键快显功能表
The right-click context menu provides the same controls on the toolbar.
The sorting and view mode settings for the list can only be found on the context menu.
View Mode
List
Displays named views as a list.
Thumbnails
Displays named views as thumbnail previews.
Sort By
Name Ascending
Sorts the list from A to Z.
Name Descending
Sorts the list from Z to A.
Clicking the name column header switches sorting order between ascending and descending.
Custom Order
Allows to sort the list using drag and drop, or the
and
buttons on the toolbar.
Custom order can be remembered when switching to other sorting methods.
