Rectangle
| Toolbar | Menu |
|---|---|
|
|
Curve Rectangle > <Options> |
Rectangle 指令用以画出一个封闭的矩形多重直线。
步骤
-
指定对角的两个点绘制基础矩形。
或者，选择其中一个选项以不同的方式绘制矩形。
(Default)
Draws the rectangle using two opposite corners.
3Point
Draws the rectangle using two adjacent corner locations and a location on the opposite side.
EdgeMidpoint
Draws the rectangle from the midpoint of the first edge, an end of the edge, and a location on the opposite side.
Vertical
Draws the rectangle perpendicular to the construction plane.
Center
Draws the rectangle from the center point and a corner.
AroundCurve
Draws a rectangle perpendicular to a curve.
圆角
将矩形四个角倒圆。
步骤
指定圆的半径。
